MXN 22 C Color/ auto heated infra red ball camera 130°
article number
675100515
In stock
€389.95
Dode-hoekcamera kleur, infrarood, beeldhoek 130°, met ingebouwde verwarming IP69k
• 1/3” color CCD high resolution image sensor • IP69K waterproof rating • Built-in IR LED’s • Diagonal 20° (MXN22C-020) 40° (MXN22C-040) 78° (MXN22C-078) or 130° (MXN22C) viewing • Auto iris • Normal/Mirror image adjustable • Built-in microphone (for one-way audio) • Multi purpose (frontview, sideview, rearview, surveillance, etc) • Built-in automatic heater (below +10°C) • Anti-corrosive 3-fold coating • Temp. -40°C ~ 80°C • Vibration resistant (10G) • CE marked • EMC approved
SPECIFICATIONS Image sensor : Picture elements : Resolution : S/N ratio : Minimum illumination : Power range : Power consumption :
Operating temperature : Diagonal viewing angle :
Dimension : Weight :
MXN22C 1/3” Sony super HAD color CCD 470.000 pixels (PAL) 520 TV lines Minimum 44dB (at AGC off) 0 lux (IR LED’s on) DC 9 ~ 28V DC 12V, 350mA (heater on) DC 12V, 110mA (heater off) -40°C to +80°C MXN22C-020: 20°(D) x 16°(H) x 13°(V) MXN22C-040: 40°(D) x 29°(H) x 22°(V) MXN22C-078: 78°(D) x 62°(H) x 46°(V) MXN22C: 100°(H)x73°(V)x130°(D) Ø 52 mm, 72(W) x 51(D) x 63(H) incl. bracket Approx. 215g
• 1/3” color CCD high resolution image sensor • IP69K waterproof rating • Built-in IR LED’s • Diagonal 20° (MXN22C-020) 40° (MXN22C-040) 78° (MXN22C-078) or 130° (MXN22C) viewing • Auto iris • Normal/Mirror image adjustable • Built-in microphone (for one-way audio) • Multi purpose (frontview, sideview, rearview, surveillance, etc) • Built-in automatic heater (below +10°C) • Anti-corrosive 3-fold coating • Temp. -40°C ~ 80°C • Vibration resistant (10G) • CE marked • EMC approved
SPECIFICATIONS Image sensor : Picture elements : Resolution : S/N ratio : Minimum illumination : Power range : Power consumption :
Operating temperature : Diagonal viewing angle :
Dimension : Weight :
MXN22C 1/3” Sony super HAD color CCD 470.000 pixels (PAL) 520 TV lines Minimum 44dB (at AGC off) 0 lux (IR LED’s on) DC 9 ~ 28V DC 12V, 350mA (heater on) DC 12V, 110mA (heater off) -40°C to +80°C MXN22C-020: 20°(D) x 16°(H) x 13°(V) MXN22C-040: 40°(D) x 29°(H) x 22°(V) MXN22C-078: 78°(D) x 62°(H) x 46°(V) MXN22C: 100°(H)x73°(V)x130°(D) Ø 52 mm, 72(W) x 51(D) x 63(H) incl. bracket Approx. 215g
| Accessory brand | MXN |
|---|---|
| Barcode | 8809338840126 |
| Recommended retail price incl. VAT | 325.00 |
| Camera, Monitor feature | Infra-red, IP standardized, Normal view, mirror view, Heated |
| Camera mounting | on bodywork |
| Camera video system | PAL - EU 50 Hz 25 fps |
| Camera connector | MXN 4-PIN connector |
| Camera lens quality | CCD (Sony) Super HAD II |
| Camera viewing angle | 130° |
| Input Voltage | 12/24V geschikt |
| Additional product required | Select the desired extension or gradient cable via the related products tab. A monitor completes the installation |
| Safety (product info) | The use of a camera (system) offers optimum security, you have better (in) view of what is around your car and you can therefore prevent accidents and damage. |
